Epnu

922FE

FEATURES

922FE

Description

  • Fully electronically controlled hydraulic system with pure electric drive, easy to control, more energy-saving and environmentally friendly. Fewer maintenance items, lower maintenance costs, energy costs compared with diesel excavators to save more than 60%.
  • Large-capacity lithium iron phosphate battery, longer cycle life, better safety performance. Cobalt-free, more environmentally friendly.
  • One-key switching of operation mode, delayed extinguishing of LED lights, and more expansion contents such as voice control and 5G remote driving are also included.
  • Newly upgraded cab, green sunscreen glass, high-definition touch instrumentation with multi-function navigation keys, more ergonomic, more comfortable to drive, ride and operate.
  • Multi-module electronic fan, according to the temperature of the intelligent variable speed, can be reversed to clean, intelligent and casual, save time and worry.

Operating Weight 24,100 kg | Rated Power 165 kW | Bucket Capacity 1.0 m³

SPECIFICATIONS

Base

Operating Weight24,100 kg
Rated Power165 kW
Bucket Capacity1.0 m³

Performance

Arm Digging Force105 kN
Bucket Digging Force152.5 kN
Drawbar Pull200 kN

Transport Dimension

Shipping Length9,910 mm
Shipping Width3,090 mm
Shipping Height2,985 mm
